HEPA Filter H14 (for G100)

HEPA filters are used in the supply, exhaust and recirculation filtration of ventilation systems with the highest requirements for clean air and sterility
Download PDF Download PDF
Ask for a quote
More Information
Length305 mm
Width292 mm
Height305 mm
Flow rate1800 m³/h
Weight5.00 kg
Use:

H14 HEPA filters are used in the supply, exhaust and re-circulation filtration of ventilation systems with the highest requirements for clean air and sterility, such as:

  • in the treatment of hazardous substances (asbestos removal, heavy metals, carcinogenic dusts, cooling lubricants, etc.)
  • in demanding air-conditioning technology (operating rooms / intensive care units of hospitals, laboratories, clean rooms, etc.)
  • in highly sensitive industrial processes (pharmacy, biotechnology, chemistry, optics, food processing, microelectronics, etc.)
  • as a downstream police filter in dedusting technology


Technical data:

  • Frame: Plastic, halogen-free
  • Filter media: Highly separating micro-glass fiber paper
  • Sealing: Polyurethane, endless and homogeneously foamed
  • Filter class: H14 according to EN 1822:2009
  • Filter efficiency H 14: > 99,995% in MPPS leakproof checked
  • Moisture resistance: 100% (relative humidity)
  • Temperature resistance: 70 °C
  • Grip protection: Plastic, double-sided
