Preliminary and Intermediate Filter G3 (EU3) - for G100
Filter for the pre-filtration in ventilation systems and devices of all kinds up to fine dust filtration.
Download PDF Ask for a quote
| Length | 305 mm |
|---|---|
| Width | 47 mm |
| Height | 305 mm |
| Nominal volume flow | 5400 m³/h/m² |
| Nominal blow speed by nominal volume | 1,5 m/s |
| Starting pressure difference | 30 Pa |
| Recommended final pressure difference | 450 Pa |
Method of use:
For the pre-filtration in ventilation systems and devices of all kinds up to fine dust filtration.
Technical data:
- Frame: Cardboard frame, 47 mm wide
- Filter medium: Glass wool
- Moisture resistance: 100 % RH
- Temperature resistance: 100 °C
-
As additional protection, a fleece filter can be delivered on a roll (thickness 21mm, width 610mm, length 30m) in the quality classification G3.
